Specifications
Certification: CE/FCC/RoHS
Standard&Protocol: IEEE802.3, IEEE802.3u
Interface: 1*10/100Mbps WAN port, 3*10/100Mbps LAN ports
Antenna: 4*5dBi external antennas
Button: 1*WiFi on/off, 1* Reset/WPS button
Power: Input:100-240V—50/60Hz, 0.2A
Output:DC 9V1A
Output:DC 9V1A
Dimension: 220*141.5*49mm
LED indicator: System*1,WAN*1, LAN*1, 2.4G*1, 5G*1,WPS*1
Wireless Standards: IEEE 802.11ac/a/n 5GHz,IEEE 802.11b/g/n 2.4GHz
Data rate: 5GHz: Up to 867Mbps, 2.4GHz: Up to 300Mbps
Frequency: Simultaneous dual band 2.4 & 5GHz
Transmit Power: CE: <20dBm(2.4G), <23dBm(5G) , FCC: <30dBm
Basic Features: SSID Broadcast: Enable/Disable, Transmission Power: high, medium, low, Beamforming, MU-MIMO
Wireless Security: WPA-PSK/WPA2-PSK, WPA/WPA2, Wireless Security: Enable/Disable, WPS(WiFi Protected Set-up) fast encryption
Internet Connection Type: PPPoE, Dynamic IP, Static IP, PPPoE(Russia), PPTP(Russia), L2TP(Russia)
Operating Mode: Wireless Router Mode, Universal Repeater Mode, WISP Mode
DHCP Server: DHCP Server, DHCP Client List, DHCP Reservation
Virtual Server: Port Forwarding, DMZ Host, UPnP
Security: Client Filter, Parental Control(support black list and white list), Remote Web Management
Firewall: Forbid UDP flood attack, Forbid TCP flood attack, Forbid flood attack, Forbid WAN PING from internet
DDNS: Support DynDNS, Oray.com, 88ip
VPN: IPsec pass through, PPTP pass through, L2TP pass through, PPTP server, PPTP client,L2TP client
Special Features: PPPoE Username/password Clone, Smart WiFi Schedule, Smart Power Saving, Smart LED on/off, Tenda Cloud, Tenda App
Other: Bandwidth Control, Guest Network, IPTV, MAC Clone, System Log, Backup & Restore configurations, Firmware upgrade online, Firmware upgradeable via browser
Temperature: Operating Temperature: 0℃ ~ 40℃, Storage Temperature: -40℃ ~ 70℃.
Humidity: Operating Humidity:10% ~ 90% RH non-condensing, Storage Humidity: 5% ~ 90%RH non-condensing.
Default Settings: Default Access: tendawifi.com
Package Content: AC1200 Smart Dual-Band WiFi Router, Power Adapter, Install Guide, Ethernet Cable
